ART-1325
ARTECH
84659900
Product Description
Feature:
1. Ball screw for Z axis,it’s stable running and precision.
2. X Y axis are gear rack,it’s stable running,precision and fast.
3. DSP control system with USB port,just need the handle to operate the machine,easy and convenient.
4. Heavy duty frame and gantry,it’s very strong and stability.
Technical Parameter:
Parameters | Standard Specifications |
X Y Z axis working area | 1300x2500x200mm |
Spindle | 6kw air cooling spindle |
X Y Z traveling positioning accuracy | +-0.01/2000mm |
Table | T.slot table or vacuum table |
Vacuum pump | air cooling 5.5kw pump |
X Y Z rail and transmission | Taiwan TBI ball screw and gear rack |
Max.rapid travel rate | 50000mm/min |
Max.working speed | 30000mm/min |
Spindle speed | 18000RPM |
Driver motors | Servo motor and driver or stepper motors and drivers |
Working voltage | 220V/380V/50HZ |
Command language | G code |
Control system | DSP or NC studio/Syntec/Mach3 |
Software compatibility | Option:Artcam,Ucancam,Type3 |
Running environment | Temperature:0~45℃ Relative humidity:30%~75% |
Oil system | handle |
Frame structure | Welding structure |
Sample
1) Woodworking industry:wood crafts,picture frames cutting,handicraft carving wave plates,
wooden door production and processing.
2) Advertising industry:advertising materials such as PVC,acrylic,double color plate.
3) Stone working industry:such as natural marble,granite,artificial stone,tombstones,milepost,
ceramic tile,glass and other materials.
4) Metal industry:carving aluminum,copper,stainless steel and others.
Service
1) Engineers available to service machinery overseas.
2) 1 year guarantee for whole machine.
3) Technical support by phone,email,whatsapp and skype.If you have any problems,we will within
12 hours to solve it.
4) You will be get free training advice towards our machine in our factory.
5) If you need any component of the machine,we will provide the best price for you.
6) Friendly English version manual and operation video CD disk.
