Jinan Style 4 Axis Rotary ART1325 3d Wood Carving Cnc Router

Quantity:

Jinan 4 axis rotary 3d wood carving cnc router machine

1. Ball screw for Z axis.It's stable running,precision and fast.

2. X,Y axis are gear rack,steady rate transmission,fast speed and high efficiency.

3. With NC studio controll system,easy to learn design software,just install it onto

your computer and start creating patterns.

4. This cnc router is installed the rotary at side machine body.So that no need to remove

the rotary whenever you work on flat bed or rotary.You just need to move the spindle

over flat bed or rotary each by the controller.It is easier to move it and save must time.

Technical Parameter:

Model

ART1325 cnc router machine

X,Y,Z Working area

1300*2500*200mm

Spindle power

3kw water cooling spindle

Spindle speed

24000rpm/min

Inverter

fuling inverter

Table structure

T.slot

Frame

Steel square tubes

Transmission type

X Y rack pinion,Z ball screw

Max.travelling speed

50000mm/min

Max.working speed

30000mm/min

Positioning accuracy

+_0.01/200mm

Motor and drives

Hybride servo motors

Command languageG code*u00*mmg*plt
Working voltage220v/50 hz
RotaryDiameter 110mm
Dust collectoroption
Control systemNCstudio
SoftwareARTCAM/Type3
CollectER25
Net weight1200KG












Jinan 4 axis rotary 3d wood carving cnc router machine samples

3130975268aa3209f51e2adbc905f7756_9k=

Jinan 4 axis rotary 3d wood carving cnc router machine service

1) 1year guarantee for whole machine from production date(except

consumable parts)within guarantee under normal use and maintenance,

if something is wrong with the machine,you will get spare part for free.



2) Technical support by phone,email,whatsapp and skype.Friendly English

manual and opperation video CD disk.Engineer available to service

machinery overseas.You will also get technical supporte and service

all the life time.



3) Normal machine is properly adjusted before dispath.You will be able

to use the machine immediately after received machine.You will be able to

get free training advice towards our machine in our factory.
