ART-1325
ARTECH
8465990000
Product Description
Feature of wood cutting machine:
1. Ball screw for Z axis.It's stable running,precision and fast.
2. X,Y axis are gear rack,steady rate transmission,fast speed and high efficiency.
3. With NC studio control system,easy to learn design software,just installed it onto your computer and start creating patterns.
4. With vacuum table,holiding the materials with vacuum pumps,you can do variety of high precision works.
5. Heavy duty frame and gantry,it's very strong and stability.
Parameter of wood cutting machine:
Parameters | ART-1325T |
X,Y,Z Working Area | 1300*2500*200mm |
Spindle Power | 3KW water cooling spindle |
Table Surface | vacuum table or T.slot table |
X,Y,Z Rail and Transmission | Taiwan TBI Ball Screw |
Max. Rapid Travel Rate | 50000mm/min |
Max. Working Speed | 30000mm/min |
Spindle Speed | 24000RPM |
Drive Motors | Stepper motors and drivers or servo motors and drivers |
Working Voltage | AC380V/3PH/50Hz or 220V |
Command Language | G Code |
Operating System | NC studio or DSP/Mach3/Syntec |
Software Compatibility | Option:Type3, Ucancam, Artcam, solidworks,etc. |
Running Environment | Temperature: 0℃~45℃ Relative Humidity: 30%~75% |
Oil system | Handel |
Frame structure | Welding structure |
Application of wood cutting machine:
1. Woodworking industry:wood crafts,picture frames cutting,handicraft carving wave plates,wooden door production and processing.
2. Advertising industry:advertising materials such as PVC,acrylic,double color plate.
3. Stone working industry:such as natural marble,granite,artificial stone,tombstones,milepost,ceramic tile,glass and other materials.
4. Metal industry:carving aluminum,copper,stainless steel and so on.
Sample
Service
After Sale Service of wood cutting machine:
1. Engineers availbal to service machinery overseas.
2. 1 year guarantee for whole machine.
3. Technical support by phone,e-mail,whatsapp and skype.If you have any problems,we will within 12 hours to solve it.
4. You will be get free training advice towards our machine in our factory.
5. If you need any component of the machine,we will provide the best price for you.
6. Friendly English version manual and operation video CD disk.
