ART6090UV Uv Printer Machine

Quantity:

ART6090UV 6090 UV flatbed uv printer

l Equipped with Japanese EPSON DX5/DX7/XP600/TX800/Ricoh GH2220 heads

l With white ink stir function and ink level alarm function

l CMYK white and varnish optional for glossy surface and high quality printing

l Taiwan HIWIN guide rail for stable working

l 900mm WIDTH is much faster than 600mm width printer

l Can print flat materials or cylindrical objects, such as pen, bottle and cup, etc

Product Model

ART6090UV  uv flatbed printer

Printhead Technology

Drop-on demand piezo electric

Printhead Control

Printhead voltage is software adjustable

Printhead Type

EPSON DX5/DX7/XP600/TX800/RICOH GH2220

Printhead Number

2/3(EPSON) 6 heads(GH2220)

Ink Characteristics

UV Curing Ink

Ink Reservoirs

Refillable on the fly while printing/1000ml per color

LED UV Lamp

More than 20000-hours life

Color Control

ICC based color, curves and density adjustment

Printhead Arrangement

CMYKW varnish optional        3-12sqm/h

Cleaning System

Positive Pressure Cleaning

Guide Rail

Taiwan HIWIN

Working Table

Vacuum Sucking/ Glass Table

Printing Size

900*600mm

Print Interface

USB2.0

Media Thickness

0-100mm, higher can be customized

Print Resolution

360*1080dpi, 720*720dpi, 720*1080dpu,720*1440dpi

Life of Printed Image

3 years(outdoor),10years(indoor)

File Format

TIFF,JPEG,Postscript3,EPS,PDF etc.

RIP Software

RipPrint/ Photoprint optional

Power Supply

220V 50/60Hz(10%) >15A

Powder

1100W

Operation Environment

Temperature 20 to 28℃, Humidity 40% to 60%

Machine Dimension

1060*2100*1160mm

Packing Dimension

1260*2250*1360mm

Weight

 300kg

Warranty

12 Months exclude the consumables


ART6090UV uv printer machine6
