ART6090TS Small Size Stone Cnc Router

Quantity:



Small size stone cnc router

1)Ball screw for Z axis.It's stable running,precision and fast.

2)X,Y axis are gear rack,steady rate transmission,fast speed and high efficiency.

3)With water tank and air cooling spindle,can protect the tool and prolong the using life.

4)DSP control system with USB port,just need handle to operate the machine.

Model
ART-6090TS cnc router Machine
X,Y,Z Working area
600*900*200mm
Spindle power
2.2kw air cooling Spindle
Spindle speed
18000rpm/min
Inverter
fuling inverter
Table structure
Iron
Frame
Steel square tubes
Transmission type
XY rack pinion,Z-ball screw
Max.traveling speed
50000mm/min
Max.working speed
30000mm/min
Positioning accuracy
±0.01/2000mm
Motor and drivers
stepper motors
Command language
G code*.u00*.mmg*.plt
Working voltage
220 V/ 3 phase /50 hz
rotary
Diameter 110mm
Dust collector
Option
Control system
DSP
Software
ARTCAM/Type3
Collect
ER20
Net weight
500KG


Small size stone cnc router samples

Small size stone cnc router samples

Small size stone cnc router service

1) 1year guarantee for whole machine from production date(except consumable parts)

within guarantee under normal use and maintenance,if something is wrong with the

machine,you will get spare part for free.



2) Technical support by phone,email,whatsapp and skype.Friendly English manual and

opperation video CD disk.Engineer available to service machinery overseas.You will also

get technical supporte and service all the lifetime.



3) Normal machine is properly adjusted  before dispath.You will be able to use the machine

immediately after received machine.You will be able to get free training advice towards

our machine in our factory.



4) 24 hours technical support by e-mail, calling service If you have any problems,

we will within 12 hours to solve it .



5) If you need any component of the machine later ,we will provide the best

price for you.
