Product Description
Mini cnc router cutting machine
1)Integral cast iron frame,more durability.
2)With Fuling Inverter: More stable Performance and easy to operation.
3)Taiwan TBI ball screw for Z axis, high precision, smooth transmission.
4)Distinct from ART6090T 3 axis cnc router,the rotary is put on the table and the
Z axis space is enlarge to give enough working area for Z axis.Rotary cnc router
take extra jobs for removing but save width.
Technical Parameter:
Item | ART6060T cnc router |
X,Y,Z Working Area | 600*600*200mm(can be customized) |
Table Size | 600*600mm |
X,Y,Z Traveling Positioning Accuracy | ±0.03/300mm |
X,Y,Z Re-positioning Accuracy | ±0.03mm |
Table Surface | Aluminum/Vacuum and T-slot Combined (Option: T-slot Table) |
Frame | Welded Structure |
X, Y Structure | 3 axis ball screw, Taiwan CSK Rail Linear |
Z Structure | Taiwan Hiwin Rail Linear Bearings |
Max. Rapid Travel Rate | 50000mm/min |
Max. Working Speed | 25000mm/min |
Spindle Power | 2.2 kw |
Spindle Speed | 0-24000RPM |
Drive Motors | Stepper/Servo motor and drive( Japan YASKAWA/Panasonic) |
Working Voltage | AC380V/50/60Hz,3PH (Option: 220V)) |
Command Language | G code |
Operating System | Original NC studio/DSP/MARCH3 controller system |
Collect | ER20 |
X,Y Reporsition | <0.03mm |
Software Compatibility | Type3/Artcam/ Software (Option: UcancameV9 Software) |
Rotary | 80mm diameter |
sample
Mini cnc router cutting machine samples
service
Mini cnc router cutting machine service
