ART2128VD Cnc Router Vacuum Table DSP

Quantity:

ART2128VD cnc router vacuum table DSP

1) Ball screw for Z axis.It’s stable running,precision and fast.

2)X,Y axis are gear rack,steady rate transmission,fast speed and high efficiency.

3)DSP control system with USB port,just need the handle to operate machine,

easy and convenient.

Auto feeding furniture production line is based on cnc router, with functions of

Auto feeding materials, automatic layout optimization and improve material utilization

by some affiliated equips.



Model

ART2128V cnc router 2040

X,Y,Z Working area

2100*2800*200mm

Spindle power

5.5kw water cooling spindle

Spindle speed24000rpm/min

Inverter

fuling inverter

Table structure

vacuum table + 7.5kw vacuum pump

Frame

Steel square tubes

Transmission type

X Y rack pinion,Z ball screw

Max.travelling speed

50000mm/min

Max.working speed

30000mm/min

Positioning accuracy

+_0.01/200mm

Motor and drives

 stepper motors

Command languageG code*u00*mmg*plt
Working voltage380v/3 phase/50 hz
vacuum pump7.5kw air cooling
Dust collectoryes
Control systemDSP A11
SoftwareARTCAM/Type3
CollectER32
Net weight1000KG


ART2040V  cnc router vacuum table DSP samples

woodworking cnc router

ART2040V cnc router 2040 vacuum table DSP service

1) 1year guarantee for whole machine from production date(except consumable parts)

within guarantee under normal use and maintenance,if something is wrong with the

machine,you will get spare part for free.



2) Technical support by phone,email,whatsapp and skype.Friendly English manual

and opperation video CD disk.Engineer available to service machinery overseas.

You will also get technical supporte and service all the lifetime.



3) Normal machine is properly adjusted before dispath.You will be able to use the

machine immediately after received machine.You will be able to get free training

advice towards our machine in our factory.



4) 24 hours technical support by e-mail, calling service If you have any problems,

we will within 12 hours to solve it .



5) If you need any component of the machine later ,we will provide the best price

 for you.
