ART2013-2-6 Cnc Router Wood Cutting Machine

ART2013-2-6 cnc router wood cutting machine
T.slot table
2.2kw water cooling spindles*6
NC studio controller system
fuling inverter
working area is 2000x1300x200mm
Quantity:

Wood cnc router cutting machine

1) Ball screw for Z axis.It’s stable running,precision and fast.

2)X,Y axis are gear rack,steady rate transmission,fast speed and high efficiency.

3)With NC studio controller system,economic and durable.

4)  Multi spindles can work at the same time, and the machine can improve the

engraving efficiency.

5)Distinct from ART1613-6 6 spindles cnc wood router cutting machine this

machine was designed with two heads.

Model

ART2013-2-6 cnc router machine

X,Y,Z Working area

2000*1300*200mm

Spindle power

2.2kw water cooling spindle*6

Spindle speed24000rpm/min

Inverter

fuling inverter

Table structure

T.slot

Frame

Steel square tubes

Transmission type

X Y rack pinion,Z ball screw

Max.travelling speed

50000mm/min

Max.working speed

30000mm/min

Positioning accuracy

+_0.01/200mm

Motor and drives

Hybride servo motors

Command languageG code*u00*mmg*plt
Working voltage380v/3 phase/50 hz
RotaryDiameter 110mm
Dust collectoroption
Control systemNC studio
SoftwareARTCAM/Type3
CollectER25
Net weight1500KG






Wood cnc router cutting machine samples

Wood cnc router cutting machine samples

Wood cnc router cutting machine service

1) 1year guarantee for whole machine from production date(except consumable parts)

within guarantee under normal use and maintenance,if something is wrong with the

machine,you will get spare part for free.



2) Technical support by phone,email,whatsapp and skype.Friendly English manual and

opperation video CD disk.Engineer available to service machinery overseas.You will

also get technical supporte and service all the lifetime.



3) Normal machine is properly adjusted before dispath.You will be able to use the machine

immediately after received machine.You will be able to get free training advice towards our

machine in our factory.



4) 24 hours technical support by e-mail, calling service If you have any problems ,we will

within 12 hours to solve it .



5) If you need any component of the machine later ,we will provide the best price for you.
