ART1530F Metal stainless steel 500w fiber laser cutting machine

Quantity:

Metal stainless steel 500w fiber laser cutting machine technical parameter



1

Machine Name

ART-1530F Fiber laser cutting machine

2

Laser machine cutting area

1500x3000mm

3

Cutting thickness

0.2-6mm stainless steel/0.2-12mm steel

4

Laser power

300w/500w/750w/1000W/1200W

5

laser device

Raycus / IPG

6

Laser wave length

1080nm

7

Transmission system

Imported ball screw /

Gear rack(optional)

8

X.Y axis location accuracy

±0.01mm

9

X.Y axis repeat location accuracy

±0.01mm

10

X.Y axis max moving speed

30m/min

11

Max cutting speed

1--16m/min

12

Min cutting line with

0.02mm

13

Machine area size

4.0x2.2x1.5m

14

Water chiller

 Constant temperature water chiller

15

Controller

NC studio

16

weight

 2500kgs

17

Red dot position

Yes


Metal stainless steel 500w fiber laser cutting machine samples

fiber laser cutting machine 500w


Metal stainless steel 500w fiber laser cutting machine service

1) 1year guarantee for whole machine from production date(except consumable parts)

within guarantee under normal use and maintenance,if something is wrong with the

machine,you will get spare part for free.



2) Technical support by phone,email,whatsapp and skype.Friendly English manual

and opperation video CD disk.Engineer available to service machinery overseas.

You will also get technical supporte and service all the lifetime.


3) Normal machine is properly adjusted before dispath.You will be able to use
the machine immediately after received machine.You will be able to get free
training advice towards our machine in our factory.
