ART1325TR Disassemble Cnc Router Woodworking Rotary on The Table Mach 3 Controller

Quantity:

 woodworking cnc router with rotary on table

1) Ball screw for Z axis.It’s stable running,precision and fast.

2)X,Y axis are gear rack,steady rate transmission,fast speed and high efficiency.

3)Mach3 control system,it's high precision.

This rotary woodworking cnc router can work for panel and cylinder.The rotary is put on

the table and the Z axis space is enlarge to give enough working area for Z axis.Rotary

cnc router take extra jobs for removing but save width.

There are another model rotary cnc router that no need to remove the rotary whenever

you work on flat bed or rotary,such as cnc router with rotary carving cylinder wood and

flat panek wood,you just need to move the spindle over flat bed or rotary each by the controller.

Model

ART1325 cnc router machine

X,Y,Z Working area

1300*2500*200mm

Spindle power

4.5kw water cooling spindle

Spindle speed24000rpm/min

Inverter

fuling inverter

Table structure

T.slot table

Frame

Steel square tubes

Transmission type

X Y rack pinion,Z ball screw

Max.travelling speed

50000mm/min

Max.working speed

30000mm/min

Positioning accuracy

+_0.01/200mm

Motor and drives

Hybride servo motors

Command languageG code*u00*mmg*plt
Working voltage380v/3 phase/50 hz
RotaryDiameter 110mm
Dust collectoroption
Control systemMach3
SoftwareARTCAM/Type3
CollectER25
Net weight1500KG













Mach3 controller woodworking cnc router with rotary on table sampleswood panel cutting machine


Mach3 controller woodworking cnc router with rotary on table service



1) 1year guarantee for whole machine from production date(except consumable parts)within

guarantee under normal use and maintenance,if something is wrong with the machine,you

will get spare part for free.



2) Technical support by phone,email,whatsapp and skype.Friendly English manual and

opperation video CD disk.Engineer available to service machinery overseas.You will

also get technical supporte and service all the lifetime.



3) Normal machine is properly adjusted before dispath.You will be able to use the

machine immediately after received machine.You will be able to get free training

advice towards our machine in our factory.



4) 24 hours technical support by e-mail,calling service if you have any problems,

we will within 12 hours to solve it.



5) If you need any component of the machine later ,we will provide the best

price for you.





4) 24 hours technical support by e-mail, calling service If you have any problems,

we will within 12 hours to solve it .



5) If you need any component of the machine later ,we will provide the best price

 for you.
