Home » Products » CNC Router Machine » CNC Router-Woodworking » ART1325ATC auto-tool changer woodworking cnc router for furniture
Share to:

ART1325ATC auto-tool changer woodworking cnc router for furniture

Quantity:

High quality auto-tool changer woodworking cnc router for furniture

1) Ball screw for Z axis.It’s stable running,precision and fast.

2)X,Y axis are gear rack,steady rate transmission,fast speed and high efficiency.

3)With NC studio controller system,economic and durable.

4)Dust shroud covers the spindle and vacuums out sawdust and wood chips while you’re cutting.

5)Heavy duty steel machine bed,it is very strong and stability.

This ART1325 atc wood cnc router with auto-tool changer,designed with round or carousel

type auto tool changer. Different knife can be installed in tool holder. spindles work one by

one,more convenient to change the tool,high efficiency and save time.Heavy duty frame

and gantry,very strong and stability.

If you don’t need this atc wood cnc router,you can option other linear auto-tool changer cnc

woodworking router machine with 2 heads,such as this atc wood cnc router ,it’s also convenient

and high efficiency.

Technical Parameter:

Parameter

Standard specifications

X,Y,Z Working Area

1300*2500*250mm multi functions wood cutter

Spindle Power

ATC air cooling spindle

X,Y,Z Traveling Positioning Accuracy

±0.01/2000mm

Table

vacuum absorbtion table

vacuum pump

 air cooling 5.5kw pump

X,Y,Z Rail and Transmission

Taiwan TBI Ball Screw and gear rack

Max. Rapid Travel Rate

50000mm/min

Max. Working Speed

30000mm/min

Spindle Speed

18000RPM

Drive Motors

servo motor and driver

Working Voltage

AC380V/3PH/50Hz or 220V

Command Language

G Code

Operating System

Nc studio controller atc

Software Compatibility

Option:Type3, Ucancam, Artcam, solidworks,etc.

Running Environment

Temperature: 0℃~45℃

Relative Humidity: 30%~75%

Parameters

Standard Specifications

Oil system

 Handel

Frame structure

Welding structure

Collect

 ER32 collect

Dust collector

1 pieces

wireless wheel

Yes






























High quality auto-tool changer woodworking cnc router for furniture samples

woodworking cnc router

High quality auto-tool changer woodworking cnc router for furniture service



1) 1year guarantee for whole machine from production date(except consumable parts)

within guarantee under normal use and maintenance,if something is wrong with the

machine,you will get spare part for free.



2) Technical support by phone,email,whatsapp and skype.Friendly English manual

and opperation video CD disk.Engineer available to service machinery overseas.

You will also get technical supporte and service all the lifetime.



3) Normal machine is properly adjusted before dispath.You will be able to use the

machine immediately after received machine.You will be able to get free training
advice towards our machine in our factory.

4) 24 hours technical support by e-mail, calling service If you have any problems ,
we will within 12 hours to solve it .

5) If you need any component of the machine later ,we will provide the best price
for you.
