Home » Products » CNC Router Machine » CNC Router-Woodworking » ART1325 Wood Panel Cutting Machine Wood Working Cnc Router with Automatic Loading And Unloading System
Share to:

ART1325 Wood Panel Cutting Machine Wood Working Cnc Router with Automatic Loading And Unloading System

Quantity:

Wood panel cutting machine with automatic loading and unloading system

1)the machine was designed with SYNTEC control system. And it is easy to learn and operate.

2)Good effect of processsing:High precision , cutting material very smoothly , Automatic design,

automatic classification, without human intervention.

3)Improve work efficiency:Auto feeding materials, automatic layout optimization , improve

material utilization.

4)Save working time:Automatic feeding , save the time of labor , no human intervention,

minimizing error rate to minimum , ensure the quality of the order.

Model

ART1325w cnc router

Working Area (X,Y,Z Axis)

1300*2500*300mm(can be customized)

Spindle

I air cooling spindles

Drilling head

5+4

Software

 Cabinet design software (optional)

Spindle Speed

Adjustable 0-18,000 rpm

Optional:Tool Changer

Auto Tool-Change

Working accuracy

±0.02

Maximum Travel Speed

60m/min

Inverter

FULING/delta

Drive System (X & Y Axis)

Rack and pinion transmission,Taiwan  square Guide rail

Drive System (Z Axis)

Taiwan TBI rolling ball screw,Taiwan  square guide rail

Electrical parts

Schneider

Motor and Driver

Japan Yaskawa Servo Motor and Drive

Working table

Vacuum table

Vacuum pump

7.5kw Water cooling

Lubrication Systems

Automatic oiling system

Control system

Taiwan Syntec control system

Power Requirements

AC380V/50HZ-3 Phase (Optional:220V)

Command

G code (HPGL,U00,mmg,plt)








Wood panel cutting machine with feeding loading and unloading system samples

wood panel cutting machine

Wood panel cutting machine with automatic loading and unloading

system service

1) 1year guarantee for whole machine from production date(except consumable parts)

within guarantee under normal use and maintenance,if something is wrong with the

machine,you will get spare part for free.



2) Technical support by phone,email,whatsapp and skype.Friendly English manual and

opperation video CD disk.Engineer available to service machinery overseas.You will also

get technical supporte and service all the lifetime.



3) Normal machine is properly adjusted  before dispath.You will be able to use the machine

immediately after received machine.You will be able to get free training advice towards

our machine in our factory.



4) 24 hours technical support by e-mail, calling service If you have any problems,

we will within 12 hours to solve it .



5) If you need any component of the machine later ,we will provide the best

price for you.
