ART-1016UV Flatbed UV Printer

Quantity:

ART-1016UV Flatbed UV Printer

l Japanese imported EPSON DX5/DX7/XP600/TX800 heads and RICOH GEN5, RICOH GH2220, TOSHIBA CE4 heads optional

l CMYK white and varnish optional for glossy surface and high quality printing

l Upgraded negative pressure system to ensure high accuracy 0.01kp difference for high quality printing performance

l Vacuum bed to hold the flexible media like PVC, foam board, acrylic sheet etc.

l Applications in advertising& signage industry and decoration industry

l Can print on Glass, Metal, Ceramic Tiles, PVC, Acrylic, Leather, Plastic, Wood, etc.

Product Model

ART-1016UV Flatbed 3d UV printer

Printhead Technology

Drop-on demand piezo electric

Printhead Control

Printhead voltage is software adjustable

Printhead Type

EPSON DX5/DX7/XP600/TX800/RICOH GEN5/GH2220/TOSHIBA CE4

Printhead Number

2/3/4/6/8

Ink Characteristics

UV Curing Ink

Ink Reservoirs

Refillable on the fly while printing/1000ml per color

LED UV Lamp

More than 20000-hours life

Color Control

ICC based color, curves and density adjustment

Printhead Arrangement

CMYKW varnish optional        3-12sqm/h

Cleaning System

Automatic Cleaning System, Automatic Dry-preventing System

Guide Rail

Taiwan HIWIN

Working Table

Vacuum Sucking

Printing Size

1000*1600mm

Print Interface

USB2.0

Media Thickness

0-100mm

Print Resolution

300dpi, 360dpi, 600dpi, 720dpi, 900dpi, 1200dpi,1440dpi

Life of Printed Image

3 years(outdoor),10years(indoor)

File Format

TIFF,JPEG,Postscript,EPS,PDF etc.

RIP Software

RIPPrint/ Photoprint

Power Supply

220V 50/60Hz(10%)

Power

1100W

Operation Environment

Temperature 20 to 30℃,Humidity 40% to 60%

ART-1016UV Flatbed UV Printer6
