A3 UV Printer

Quantity:

l Equipped with Japanese EPSON XP600/TX800/DX7/DX5 heads

l Use non-VOC environmenta

l UV curing ink, clear and perfect printing quality

l Color with CMYK and White optional for high quality printing

l Use high precision mute liner guide rail, long service life, high stability

l LED cold light lamp UV curing system, no heat radiation.

l Utilize high mute drag chain, ideal for protection of cable and tubes under high speed motion.

l Can print on PVC board, glass, plastic, organic board, leather, rubber, special paper, metal, wood, porcelain, PVC, ABS, acrylic, aluminum, iron sheet, ceramic tile, marble, granite,       paperboard etc



Product Model

A3  Size UV Flatbed Printer

Printhead Technology

Drop-on demand piezo electric

Printhead Type

EPSON XP600/TX800/DX7/DX5

Printing Size

300*500mm

Print Height

0-25cm

Print resolution

1440*2880 dpi



Printing speed



720 dpi  50 seconds/A4 size

1440 dpi  100 seconds/A4 size

2880 dpi  200 seconds/A4 size

Cooling System

Water cooling system

Interface

USB2.0

Ink colors

C, M, Y, K, W

Ink type

UV LED curing ink

Lamp type

LED Lamp (saving energy and environmental friendly)

Power Consumption

110-220V, 50HZ-60HZ 75W

Working environment

Temperature 0-30 Celsius Humidity 40-70RH

Software

Maintop

File Format

Tiff, Jpeg, PDF

Machine size

780mm x 830mm x 516mm

Package size L*W*H

830mm x 880mm x 560mm

Net Weight

70 KGs

Gross Weight

110 KGs

A3 UV Printer6




A3 UV Printer
