Product Description
1.Ball screw for Z axis.It’s stable running,precision and fast.
2.X,Y axis are gear rack,steady rate transmission,fast speed and high efficiency.
3.DSP control system with USB port,just need the handle to operate the machine,easy and convenient.
4.With vacuum table,holding the materials with vacuum pump,you can do varoety of high precision works.
5.Heavy duty frame and gantry,it’s very strong and stability.
Technical Parameter
Description | Parameter |
X Y Z axis working area | 1300x2500x200mm |
Spindle | 3.5kw air cooling spindle |
X Y Z traveling positioning accuracy | +-0.01/2000mm |
Table Surface | T.slot table or vacuum table |
Vacuum pump | air cooling 5.5kw pump (option) |
X Y Z rail and transmission | Taiwan TBI ball screw and gear rack |
Max.rapid travel rate | 50000mm/min |
Max.working speed | 30000mm/min |
Driver motors | stepper motor and drivers or servo motor and drivers |
Working voltage | 220V/380V/50HZ |
Command language | G code |
Control system | DSP or NC Studio/Syntec/Mach3(option) |
Software compatibility | Option:Artcam,Ucancam,Type3 |
Running environment | Temperature:0~45ºC Relative humidity:30%~75% |
Oil system | Manual oil lubrication system |
Frame structure | New type thicker and bigger heavy duty square tube |
Application
1.Woodworking industry:wood crafts,picture frames cutting,handicraft carving wave plates,wooden door production and processing.
2.Advertising industry:advertising materials such as PVC,acrylic,double color plate.
3.Stone working industry:such as natural marble,granite,artificial stone,tombstones,milepost,ceramic tile,glass and other materials.
4.Metal industry:carving aluminum,copper,stainless steel and so on.
Package and Delivery
Package Detail:1.Outside:Standard plywood package.
2.Inner package:Stretchy film and plastic film for humidity.
And we can package according to you requests
Delivery Detail:For standard machines,it will be 7-15 working days after payment;For non-standard machines and customized machines according to clients’ specific requirements,it will be 15-30 working days after payment.
After Sale Service
1.Engineers available to service machinery overseas.
2.1 year guarantee for whole machine.
3.Technical support by phone,e-mail,whatsapp and skype.If you have any problems,we will within 12 hours to solve it.
4.You will be get free training advice towards our machine in our factory.
5.If you need and component of the machine,we will provide the best price for you.
6.Friendly English version manual and operation video CD disk.
Company Inormation
ARTECH CNC EQUIPMENT CO.,LTD is comprehensive in the production,design,manufacturing,trade and service of CNC machine,and provide high quality and good efficient CNC machines worldwide.With a strong staff team,gained success in woodworking engraving machine,advertising engraving machine,stone engraving machine,metal engraving machine,laser engraving and laser cutting industry equipment.The production facilities occupies China’s forefront in development and expansion.
