Home » Products » CO2 Laser cutting machine » Laser cutting machine » ART6040L factory direct sale mini portable nonmetal 3d laser cutting machine
Share to:

ART6040L factory direct sale mini portable nonmetal 3d laser cutting machine

Quantity:

Mini protable nonmetal 3d laser cutting machine

1)For cutting/engraving.(This machine can cut carbon,steel,iron,stainless steel and other

metals,and can also cut and engrave max acrylic,wood,plywood,leather and MDF etc. )

2)Economic,cost-effective multi functional laser cutting machine.

3)Non-contact metal cutting auto-following device,to cut all kinds of materials with less investment.

4)Equipped with the RECI/YONGLI/EFR laser tube,longer laser life and more stable performance.

5)Ruida or Leetro control system,PMI guide rails and high quality belt transmission.

6)The USB interface supports data transmission for quick completion.

7)Lens and mirror imported from singaproe.

NO.

Description

Parameter

1

Model

ART6040L co2 laser cutting machine

2

Working area

600x400mm

3

Transmission

stepper motor&belt/servo motor&ball screw

4

Laser power

80w/100w/130w/150w/180w/280w/300w

5

Laser type

sealed co2 laser tube

6

Cooling type

water cooling

7

Laser output control

0-100% set by software

8

Smallest character

Chinese 2.0mm*2.0mm,English 1.0mm*1.0mm

9

Positioning accuracy

 0.05mm/0.02mm

10

Max. cutting thickness

40mm

11

Max. cutting speed

20m/min

12

Controling software

Ruida

13

Graphic format supportedDST,PLT,BMP,DXF,DWG,AI,LAS,etc

14

Compatible software

CORELDRAW,PHOTOSHOP,AUTOCAD,etc

15

Power supply

AC110V/220V+10%,50HZ/60HZ


Mini protable nonmetal 3d laser cutting machine samples

3d laser cutting machine

Mini protable nonmetal 3d laser cutting machine service



1) 1year guarantee for whole machine from production date(except consumable

parts)within guarantee under normal use and maintenance,if something is wrong

with the machine,you will get spare part for free.



2) Technical support by phone,email,whatsapp and skype.Friendly English

manual and opperation video CD disk.Engineer available to service machinery

overseas.You will also get technical supporte and service all the lifetime.



3) Normal machine is properly adjusted before dispath.You will be able to use the

machine immediately after received machine.You will be able to get free training

advice towards our machine in our factory.



4) 24 hours technical support by e-mail, calling service If you have any problems,

we will within 12 hours to solve it .



5)If you need any component of the machine later ,we will provide the best price

for you
